感应式马达特徵：适用于单相、三相马达单方向连续连转。

　　Characteristics of induction motor:Applicable to single-phase motor in single direction continuous operation.

　　可逆式马达特徵：适用于单相、三相马达频繁正逆转操作(30分钟额定)。

　　Characteristics of reversible motor:Applicable to 3-phase motor frequently cw/ccw operation(30 minutes rating).

　　马达一般规格Motor General Specification

　　绝缘阻抗：在马达的线圈与外壳间以DC500V高阻计测定，其数值在100MΩ以上。

　　绝缘耐压：在马达的线圈与外壳间施加50Hz或60Hz、1.5KV、1分钟无发生异常现象。温度上升：于马达额定连转后以电阻法测定，温度上升值在80℃以下。

　　绝缘等级：B种(130℃)

　　保护等级：导线型IP20，端子盒型IP54。

　　使用温度：-10℃~+50℃(电容连续运转马达-10℃~+40℃)(不结冻状态)。使用湿度：85%以下(不结露状态)。

　　Insulation impedance:Measure with DC500V high resistance gauge between the coil and casing of motor,the reading is 100M or higher.

　　Insulation resistance to pressure:Apply 50Hz or 60Hz,1.5V between the coil and casing of motor for one minute without irregularity resulted.

　　Temperature rise:To specify by resistance method after motor reaches rated operation,temperature is less than 80℃.

　　Insulation:B(130℃)

　　Protection:Motor with conductive wire is IP20;motor with terminal box is IP54.

　　Operating temperature:-10℃~+50℃(Capacitor operation motor-10℃~+40℃)(No freezing)Operating humidity:85%or less(No condensation)
